HIGH-END BIOLOGICAL MICROSCOPE QUANTUM BM
Price range: 21,13 € through 1.166,00 €
Binocular or trinocular head (depending on model) with infinity-corrected optical system and Seidentopf head inclined at 30°, interpupillary adjustment of 50-75mm, and 360° rotation. WF10x/20mm eyepieces and inverted quadruple nosepiece. Infinity plan achromatic objectives 4x, 10x, 40x, and 100x (oil), all with anti-fungal treatment. Double-layer mechanical stage of 155x142mm with X-Y movement of 76x50mm and Vernier scale of 0.1mm. Coaxial focusing system with 0.002mm precision and tension adjustment. Centered Abbe condenser N.A. 1.25 with iris diaphragm. Adjustable 3W LED illumination. 100-240 V, 50/60 Hz. 2-year warranty
Complies with the specifications defined in the European directive
Product covered by a 2-year warranty against possible manufacturing or functional defects. Excludes damage resulting from improper use or external conditions unrelated to the product.
| reference | description | pcs/pack | price/pack | available stock | quantity | |
|---|---|---|---|---|---|---|
| MP03-002-001 | binocular head | 1 | 955,20 € | 3 | ||
| MP03-003-001 | trinocular head | 1 | 1.104,00 € | 0 | ||
| MPAC-005-001 | 1 | 21,42 € | 8 | |||
| MPAC-006-001 | WF20X Eyepiece | 1 | 21,13 € | 5 | ||
| MPAC-016-001 | 20X plan-achromatic objective | 1 | 79,50 € | 5 | ||
| MPAC-017-001 | 60X plan-achromatic objective | 1 | 212,00 € | 5 | ||
| MPAC-019-001 | 0.5X C-mount camera adapter | 1 | 90,10 € | 1 | ||
| MPAC-030-001 | Turret Phase Contrast Kit | 1 | 1.166,00 € | 1 |
User manual English
Data sheet
Additional informationDescription
Binocular or trinocular head (depending on model) with infinity-corrected optical system and Seidentopf head inclined at 30°, interpupillary adjustment of 50-75mm, and 360° rotation. WF10x/20mm eyepieces and inverted quadruple nosepiece. Infinity plan achromatic objectives 4x, 10x, 40x, and 100x (oil), all with anti-fungal treatment. Double-layer mechanical stage of 155x142mm with X-Y movement of 76x50mm and Vernier scale of 0.1mm. Coaxial focusing system with 0.002mm precision and tension adjustment. Centered Abbe condenser N.A. 1.25 with iris diaphragm. Adjustable 3W LED illumination. 100-240 V, 50/60 Hz. 2-year warranty
